Resources for installers

Optimino keys and solar compatibility resources

Optimino helps Thermino work with different energy sources, including heat pumps and solar PV. You choose the Optimino key that matches the heat source you have today, and if the system changes later, you can switch to the relevant key without replacing the heat battery.

Learn more about Optimino technology here.

Optimino key part numbers

Energy Source – Heat pumps

Compatible heat pump brands	Without PV key	With PV key
Amitime PAVH-08V1GFB R290 HP	AE01	AE02
Bosch Compress 5800i AW R290	BH01	BH02
Daikin Altherma 3HHT R32 series	DN01	DN02
Ecoforest ecoAIR PRO series	ET01	ET02
Ecoforest ecoGEO PRO R290 series	ET01	ET02
Grant Aerona HPR290 series	GT01	GT02
Haier Monobloc GT R290 series	HR01	HR02
Hisa HR290	HA01	HA02
Hisense Hi-Therma R290 Monobloc Heat Pump	HE01	HE02
Ideal HP290 R290 Monobloc	IL01	IL02
LG Therma V Monobloc R290 series	LG01	LG02
Midea MHC R290	MA01	MA02
Mitsubishi Electric PUZ-WZXXVAA R290	MC01	MC02
NIBE S2125 R290	NE01	NE02
Panasonic L series R290	PC01	PC02
Phnix Greentherm R290 Series	PX01	PX02
Samsung EHS HTQ R32 Series	SG01	SG02
Samsung EHS Mono R290	SG01	SG02
Stiebel Eltron WPL-A 07 HK 230 Premium R454C HP	SL01	SL02
Stiebel Eltron HPA-O Trend HC 230 R290	SL01	SL02
Stiebel Eltron HPA-O Plus HC 230 R290	SL01	SL02
Tongyi R290 Inverter Series ‘TAHMV-R’	TI01	TI02
Trianco Activair R290 Series	TO01	TO02
Vaillant Arotherm + R290 Series	VT01	VT02
Viessmann Vitocal R290	VN01	VN02

Access all relevant guidance in one place, including heat pump manufacturer wiring instructions, xPlus technical notes for back-up electric mode, Thermino 1800W wiring diagrams with AC coil relay, and Thermino VF timer wiring instructions along with the cold commissioning procedure:
Click here to know more

Energy Source – Boiler

Heat source	Without PV	With PV key
Boiler	VF01	VF02

Energy Source – Solar PV

Heat source	PV key
Solar PV with ePlus	PV02

For the Thermino xPlus, use the PV key compatible with your heat pump, as shown in the ‘Energy Source – Heat Pumps’ table.

Solar PV

Compatible solar diverters

4-Noks power reducer SA

myenergi EDDI solar diverter

my-PV AC·THOR solar diverter

Power Diverter Model 3 solar diverter

View the full Thermino ePlus/xPlus with PV – Wiring & Settings manual.

See more resources for installers

Including installation manuals and data sheets

Visit the information hub

Find out more about the ePlus and xPlus

Check out our product pages

Find out more
